Industrial Vacuum, Chip/Coolant Recovery
• W-210CV
-
Vista general
Product Overview
For first-rate 115V electrical performance, while separating chips from the coolant, the W-210CV ChipMaster® is a machine you can depend on. Not only does it collect and separate chips down to 0.05", but it also recovers strings and clumps, due to a specially designed tangential intake port. Despite ChipMaster's large, 7-gallon capacity basket, it is still easy to drain through the gravity-fed dump valve.
Note: The product does not come with accessories. Please order VAC-KIT-5, VAC-KIT-5-G, or individual accessories. Contact Goodway for more information.
What's Included
W-210CV ChipMaster® Industrial Vacuum includes:
- W-210CV Vacuum filter w/tangential intake port
- 11-gallon metal chip basket
- 22-gallon bonderized steel drum with handles
- Casters and dump valve
-
Features & SpecsFeatures
Product Features
- Two heavy-duty motors
- Coolant level indicator
- Liquid shut-off
- 1" dump valve
- Tangential intake port
- 7 gal. metal chip basket
- 15 Gallon wet capacity
- Reusable filter
- Uses 1-1/2" or 2" hoses
- Output Power: Twin motors - 2.7 HP total
- Input power: 15 Amps, 115 V, 50/60 Hz AC
- Power supply cord: 30', 14-3
- Static water lift: 90"
- Air displacement: 224 CFM
- Dimensions: 20 1/2" diameter tank x 44" high
- Weight: 150 lbs
-
